Spindle oil

Spindle oil for hydrostatic systems and high-frequency spindles!

HiPure HLPD

Fine filtered special hydraulic fluids according ISO VG 32, 46 and 68 for your spindles
Purity class 15/13/10 according to ISO 4406

Application
Fine filtered special hydraulic fluid with detergent (cleaning) properties for hydrostatic systems.

Description
HiPure HLPD spindle oil is a fine filtered, zinc-free, paraffinbased special fluid with additives for an excellent wear protection which contributes to the aging resistance and to the improvement of the gliding performance. This product has excellent detergent and dispersing properties. Further it is characterized by its outstanding corrosion protection.

Field of application
Due to the guaranteed and high purity grade this hydraulic fluid is used for the lubrication of bearings in engines and high-frequency spindles, such as Step-Tec.

Specifications
Hydraulic fluid HLPD according to DIN 51 524-2:1985 and DIN 51502,
Purity class: 15/13/10 according to ISO 4406
8 according to SAE AS 4059

Operating
Fill into the central system device without any cross-contamination with other material. Seal the bottle carefully after using. Prevent any kind of dust during the filling process. The filling nozzle has to be cleaned before each filling.

Water hazard class: WHC 1
Waste code: EAK 13 01 10
